ESD Epoxy Flooring

Anti-Static Epoxy Self-Leveling

Reference · 54147272

A conductive epoxy flooring system for electronics and other static-sensitive spaces, applied with the specified grounding and coating layers.

AdhesionGrade 1
Compressive Strength≥ 80 · MPa
Resistance1.0×10⁶ ~ 1.0×10⁹ · Ω
Discuss this productTechnical specifications ↓
HUITUO · 54147272

Product Description

Epoxy Anti-static Self-leveling Floor

Product Introduction:

Epoxy Anti-static Self-leveling Floor is a high-performance floor material that combines the excellent properties of epoxy resin and anti-static function, widely used in places sensitive to static electricity.

Application Scope:

Epoxy Anti-static Self-leveling Floor is suitabie for electronic, microelectronic, communication product and electronic manufacturing industries that require high cleanliness, aesthetics, dust-free, sterile and anti-static environments, as well as factories.

Performance Characteristics:

1.Excellent and long-lasting anti-static effect, not affected by time, temperature, humidity, etc.;

2.Made of solvent-free epoxy resin and high-quality curing agent;

3.Smooth and beautiful surface, reaching a mirror effect;

4.Resistant to corrosion by acids, alkalis, salts, oils, especially good resistance to strong alkalis;

5.Wear, pressure and impact resistance, with certain elasticity.

Construction Process:

1.Base Treatment;

2.Apply sealing primer;

3.Lay copper wires and cut grooves;

4.Scrape and apply conductive middle coat;

5.Grind and vacuum;

6.Trowel and apply 1-2 coats of anti-static epoxy self-leveling color paint.

Technical Indicators:

‌Technical Indicator‌

‌Specification‌

‌Unit‌

Resistance

1.0×10⁶ ~ 1.0×10⁹

Ω

Adhesion

Grade 1

-

Wear Resistance

≤ 0.03

g

Compressive Strength

≥ 80

MPa

Hardness (Pencil)

≥ 2H

-

Self Leveling ESD Epoxy Flooring 80MPa Grade 1 Anti Static Floor Coating 0
Self Leveling ESD Epoxy Flooring 80MPa Grade 1 Anti Static Floor Coating 1

Technical specifications

PropertyValue
AdhesionGrade 1
Compressive Strength≥ 80 · MPa
Resistance1.0×10⁶ ~ 1.0×10⁹ · Ω
Wear Resistance≤ 0.03 · g
Hardness (Pencil)≥ 2H
